In order to create a simple 3D and 2D data visualization tool I took a look at the Visualization Toolkit. I found everything I needed there – it’s a really great collection of C++ classes with bindings for various other programming languages (TCL, Python). However the documentation is somewhat confusing and lacking simple basic things although a very good document on how to install compile and use it together with Visual Studio can be found here and a great blog aiming at overcoming the lack of tutorials can be found here.

I had quite a hard time figuring out the easiest thing: read raw 2D data and visualize it. After I played around with it for a while I figured it out. It’s actually pretty simple. Here’s the code:

/*******************************************************************************

    Simple VTK Example

    A very simple VTK example - a raw 2D datafile is read
    it's magnified by a factor of 3 and then it's displayed on a window.

    The pipeline:
    vtkImageReader->vtkImageMagnify->vtkRenderWindow

    The image file is a raw file of 64 rows * 64 columns. The values are
    2 byte (short int) long.
    It's a greyscale dataset (NumberOfScalrComponents = 1)

*******************************************************************************/

#include "vtkImageReader.h"
#include "vtkImageViewer.h"
#include "vtkImageMagnify.h"
#include "vtkRenderer.h"
#include "vtkRenderWindow.h"
#include "vtkRenderWindowInteractor.h"

#define IMG_FILE "C:data.raw"

int main (void)
{
  vtkImageReader *imgReader = vtkImageReader::New();
    imgReader->SetFileDimensionality(2);
    imgReader->SetFileName(IMG_FILE);
    imgReader->SetNumberOfScalarComponents(1);
    imgReader->SetDataExtent(0,63, 0,63, 0,0);

  vtkImageMagnify *imgMagnify = vtkImageMagnify::New();
    imgMagnify->SetInputConnection(imgReader->GetOutputPort());
    imgMagnify->SetMagnificationFactors(3, 3, 3);

  vtkImageViewer* imgViewer = vtkImageViewer::New();
    imgViewer->SetInputConnection(imgMagnify->GetOutputPort());

  vtkRenderWindow *renWindow = vtkRenderWindow::New();
    renWindow->AddRenderer(imgViewer->GetRenderer());
    renWindow->SetSize(64*3, 64*3);

  vtkRenderWindowInteractor *renWindowInteractor = vtkRenderWindowInteractor::New();
    renWindowInteractor->SetRenderWindow(renWindow);
    renWindowInteractor->Initialize();
    renWindowInteractor->Start();

  return 0;
}
